S6 Kolobrzeg 5 Cordoba LED 3.0

Cordoba LED 3.0 L

High luminous efficiency up to 142 lm/W
High resistance of the housing to corrosion and atmospheric factors
Polish product with a warranty of up to 10 years
Lifespan of up to 190,000 hours of illumination
A wide range of lenses that precisely illuminate the desired surface
Source of light : LED
CE Certification
Klasa odporności 1
II protection class
IK09 IP66
Impact Protection/Ingress Protection
220-240V 50/60Hz power supply

Cordoba 3.0 L is a powerful street luminaire, crafted for the most demanding routes such as expressways, highways, county roads, squares, and parking lots. Providing very high powers from 195 to 216W, an extensive range of control systems and protections up to 20kV, and diverse lenses adjusting the light’s angle, it guarantees unparalleled quality and performance backed by ENEC and ENEC+ certificates and a warranty up to 10 years.

Cordoba LED 3.0 L: Revolutionary Lighting for Highways and Urban Spaces



Power and Adaptability for a Wide Range of Applications
Cordoba LED 3.0 L, available in two power versions – 195 and 216 watts – has been designed to meet advanced lighting needs, such as highways, motorways, county roads, as well as urban squares and parking lots. This luminaire combines high performance and adaptability, meeting lighting requirements for a wide spectrum of public spaces.



Lighting Efficiency and Resilience
Characterized by an impressive luminous efficacy of up to 142 lm/W, Cordoba LED 3.0 L ensures optimal lighting while maintaining energy efficiency. Corrosion resistance and resilience to adverse weather conditions ensure reliable operation and durability even in demanding outdoor conditions.



Longevity of a Polish Product
As a high-quality product manufactured in Poland, Cordoba LED 3.0 L comes with a ten-year warranty, confirming the manufacturer’s confidence in its durability. With a luminaire lifespan of up to 190,000 hours, the need for frequent replacements is minimized, which is crucial for lighting infrastructure with high intensity of use.



Innovative Optical Solutions
The luminaire is equipped with an advanced range of lenses that precisely direct light, providing excellent illumination of required areas. This feature is particularly important when designing lighting for highways and motorways, where precision and lighting efficiency are crucial for safety.



Flexibility in Control
Advanced control options, including DALI, MainsDIM, CLO, StepDIM, and AstroDIM systems, allow for full control over the lighting, enabling adjustment to current needs and energy consumption optimization, which is particularly important in the context of sustainable development and ecology.



Summary
Cordoba LED 3.0 L is a unique proposition among lighting systems, dedicated to areas with high requirements, such as highways, motorways, urban squares, and parking lots. By combining unmatched power, lighting efficiency, and durability with the ability for precise control, this luminaire sets new standards in urban lighting, ensuring safety, comfort, and energy efficiency.

Cordoba LED 3.0 L Applications
S6 Kolobrzeg 5 Cordoba LED 3.0
Expressways

Cordoba LED 3.0 L, available in 195 and 216 watt versions, is an excellent choice for illuminating high-speed roads, where dedicated lenses effectively illuminate areas despite the large distance between poles. Durable and long-lasting, it ensures the continuity and safety of lighting even in challenging conditions, while advanced control allows for economical energy management.

Highways

For highways, where safety and visibility are paramount, the Cordoba LED 3.0 L luminaire offers a robust lighting solution with 195 and 216 watt options. Its specially designed lenses effectively overcome the challenge of large distances between poles, providing uniform light distribution and eliminating dark areas. The luminaire is characterized by resistance to extreme weather conditions and ensures reliability for over 190,000 hours, making it an ideal choice for highway infrastructure requiring minimal maintenance with maximum efficiency.

County roads

On county roads, where safety and continuous lighting are essential, the Cordoba LED 3.0 L with 195 and 216 watt options provides an optimal solution. Its advanced lenses ensure uniform light distribution, which is crucial on less frequented but equally important routes. The luminaire’s durability in variable weather conditions and its long lifespan guarantee reliability while minimizing the need for service interventions, which is crucial for areas with limited access to rapid maintenance services.

Squares

Cordoba LED 3.0 L, available in 195 and 216 watt options, is perfectly suited for large-scale plazas, where even light distribution is crucial with a limited number of poles. Specially designed lenses ensure optimal illumination of the space, guaranteeing safety and comfort for users with minimal maintenance required.

Parking lots

In vast multi-level parking lots, where optimal space utilization is crucial, the Cordoba LED 3.0 L in 195 and 216 watt configurations provides an ideal solution. This luminaire ensures excellent visibility with even light distribution while minimizing the need for a large number of poles, allowing for more efficient management of parking space.

Product available in multiple configurations
NameProduct-CodeDimensions H x W x L [mm]Power [W].Luminosity [lm]Efficiency [lm/W]Color temperature [K]CRI/RaProtection Rating [IP]Light distribution
CORDOBA LED 3.0 9 CRD3ST.98.195.7C3000
CRD3ST.98.195.7C4000
CRD3ST.98.195.7C5700
CRD3ST.98.216.7C3000
CRD3ST.98.216.7C4000
CRD3ST.98.216.7C5700
CRD3ST.99.195.7C3000
CRD3ST.99.195.7C4000
CRD3ST.99.195.7C5700
CRD3ST.99.216.7C3000
CRD3ST.99.216.7C4000
CRD3ST.99.216.7C5700
320/98/800
320/98/800
320/98/800
320/98/800
320/98/800
320/98/800
320/98/800
320/98/800
320/98/800
320/98/800
320/98/800
320/98/800
195
195
195
216
216
216
195
195
195
216
216
216
23400 – 26400
24750 – 27900
24450 – 27550
25750 – 29100
27250 – 30750
26950 – 30400
23400 – 26600
24750 – 27900
24450 – 27550
25750 – 29300
27250 – 30750
26950 – 30400
120 – 135
126 – 143
125 – 141
119 – 134
126 – 142
124 – 140
120 – 136
126 – 143
125 – 141
119 – 135
126 – 142
124 – 140
3000
4000
5700
3000
4000
5700
3000
4000
5700
3000
4000
5700
>70
>70
>70
>70
>70
>70
>70
>70
>70
>70
>70
>70
66
66
66
66
66
66
66
66
66
66
66
66
15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150° 20°X130° 52°X130°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150° 20°X130° 52°X130°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

15°X150° 35°X150° 45°X150°
15°X150° 35°X150° 45°X150° 50°X155° 55°X150° 60°X150° 60°X160° 60°X165° 65°X40° 70°X120° 75°X50° 80°X15° 80°X150°

Customize your product variant and download the dedicated technical specification sheet

Already have a quote? Select the product family and then the product code that interests you to download an individual product sheet

BAZA-FORM-Kubatura
See the results of the Cordoba LED 3.0 L implementation for our clients
https://luxonled.eu/wp-content/uploads/2024/03/DJI_0263-scaled.jpg
CO 2

Reduction of CO2 emissions into the atmosphere

Savings

Reduction of energy costs for lighting

5

5-year warranty on the lights
