Lumitrack LED 1.0

High luminous efficacy up to 172 lm/W
Quick and simple installation
Elegant design, powder-coated aluminum housing
Several diffuser and lens variants available
5-year warranty

Source of light : LED

CE Certification

II protection class

IK03 IP20

Impact Protection/Ingress Protection

220-240V 50/60Hz power supply

LUMITRACK LED 1.0 is a linear luminaire from the Lumitrack series designed for mounting in 3-phase tracks (compatible with tracks from manufacturers listed in the assembly manual), which can also accommodate other types of fixtures, such as Tracklights and other luminaires adapted for this type of track. Featuring a luminous efficacy of up to 172 lm/W, the luminaire has a lifespan of 340,000 hours (L80B50) and a color rendering index CRI > 80. It is designed for general lighting in stores, warehouses, and corridors. The luminaire is also available in a version that allows for connection and the creation of continuous light lines.

Lumitrack Series

LUMITRACK LED 1.0 is part of a lighting system that offers full flexibility in space design. The series also includes:

Spot Version – equipped with beam direction adjustment, dedicated to accent lighting.
Linear Version – designed for creating continuous, uniform light lines.

Energy Efficiency

The LUMITRACK LED 1.0 luminaire features a luminous efficacy of up to 172 lm/W. High efficiency allows for a reduction in electricity consumption in large-scale facilities and warehouses while maintaining the required lighting intensity.

Technical Parameters and Durability

The components used ensure a lifespan of 340,000 hours (L80B50), enabling long-term continuous operation. The housing, made of powder-coated extruded aluminum, ensures optimal heat dissipation and stable lighting parameters.

Rail System Mounting

The luminaire is fully compatible with standard 3-phase tracks. The design allows for quick, tool-free installation, as well as easy repositioning and connecting of luminaires into light lines, facilitating the adaptation of lighting to the current room layout.

Light Characteristics

The device emits flicker-free light with a color rendering index of CRI > 80. The wide beam angle makes the luminaire ideal for general lighting in walkways, store aisles, and office spaces, providing uniform illumination throughout the area.

Modernization of LED lighting in the sales halls of BAT Sp. z o.o., increasing light intensity and reducing energy consumption.

Large-scale Retail

The LUMITRACK LED 1.0 is the ultimate solution for general lighting in hypermarkets. With an outstanding luminous efficacy of up to 172 lm/W, this luminaire drastically reduces energy bills while providing bright, uniform illumination across shopping aisles.

Corridors and Walkways

Designed for continuous operation, this fixture ensures safety and comfort in corridors and walkways. Its record-breaking lifespan of 340,000 hours (L80B50) means that once installed, you can “forget” about it for decades, effectively eliminating maintenance and replacement costs.

Retail Spaces

Mounting on a 3-phase track provides the flexibility essential for modern retail. The luminaire can be easily repositioned and combined with accent spotlights, creating a cohesive lighting system that adapts to changing store layouts.

Modernization of LED lighting in the production halls of Dong Yang Electronics.

Warehouses & Logistics

A robust aluminum construction (IP20) combined with high performance makes the LUMITRACK LED 1.0 a perfect fit for logistics centers. Bright, stable light improves visibility and occupational safety, while a 5-year warranty confirms its reliability in industrial environments.

Museums

As ambient background lighting, this fixture (CRI >80) subtly complements exhibition designs without distracting from the exhibits. The absence of UV radiation and flicker protects the eyesight of visitors as well as precious works of art.
