Lumiline LED 3.0

Lumiline LED 3.0

High luminous efficiency up to 147 Lm/W
Several variants of available types of diffusers
Lifespan of up to 145,000 hours of illumination
Quick and simple installation of modular luminaires
Source of light : LED
CE Certification
Klasa odporności 0
I protection class
IP20
Ingress Protection
220-240V 50/60Hz power supply

LumiLine LED 3.0 is an innovative linear lighting system, crafted with contemporary retail spaces in mind. Its advanced functionalities and adaptable design make it the prime choice for retail chains seeking efficient and aesthetic lighting solutions. The availability of two diffusers – PMMA microprismatic and frosted PMMA – allows for precise light distribution, accentuating product features and fostering a welcoming ambiance for shoppers. With a remarkable lifespan reaching up to 100,000H and available in four power variants, LumiLine LED 3.0 epitomizes the pinnacle of retail lighting solutions.

LumiLine LED 3.0: Revolution in Industrial Lighting



Innovation at Every Step
LumiLine LED 3.0 represents the pinnacle of modernity among LED lighting systems. Designed with commercial spaces in mind, its technologically advanced features and design flexibility make it seamlessly integrate into any environment. With two types of diffusers – PMMA microprismatic and PMMA frosted – you can precisely adjust the light distribution to highlight the best features of showcased products and create a friendly atmosphere for customers.



Durability and Performance
With an impressive lifespan of 145,000 hours, LumiLine LED 3.0 is an investment that pays off. Light efficiency up to 147 lm/W depending on the selected configuration not only provides energy savings but also reduces operational costs. Available in four power versions, from 11 to 76W, it allows for flexible adaptation to the needs of various spaces.



Solidity and Aesthetics
The powder-coated extruded aluminum housing ensures durability and longevity, while the available color options – standard gray (RAL 7038) and optional black (RAL 9005) – enable customization to any interior.



Ease of Installation and Configuration Flexibility
The installation of the LumiLine LED 3.0 system is quick and simple, allowing for easy implementation in any project. The possibility of connecting luminaires into light lines and a rich selection of additional accessories, enabling configuration in the form of L, U, or square, open up new possibilities for arrangement.



Advanced Control
The DALI system and additional power supply functions, such as NFC and DALI-2, provide full control over the lighting, allowing for customization to the user’s individual needs and optimization of energy consumption.



Versatile Application
LumiLine LED 3.0 performs exceptionally well in various spaces, such as warehouses, office spaces, large-scale retail stores, passageways, or commercial properties. Each of these places benefits from its functionality and aesthetics. Emphasizing key aspects such as advanced control, energy efficiency, ease of installation, and durability, LumiLine LED 3.0 is a future-proof solution that not only illuminates space but also adds a modern character to it.

Lumiline LED 3.0 Applications
Warehouses

In warehouses, it’s crucial to provide uniform and efficient lighting that enables safe and effective space management. LumiLine LED 3.0 can be installed in long light lines above warehouse aisles, providing intense but non-glaring light that facilitates quick location of goods and safe movement with heavy equipment for workers. With its modular design option, the luminaires can be customized for various warehouse configurations, including tall racks or loading and unloading areas.

Office spaces

In office spaces, flexibility in lighting is important to cater to the diverse needs of employees and tasks. The modularity of LumiLine LED 3.0 allows for the creation of varied lighting layouts that can support concentration at individual workstations as well as promote relaxation in break areas. The use of frosted PMMA diffusers is suitable for conference rooms and meeting spaces, diffusing light and minimizing the risk of glare on computer screens.

Large-format stores

Lighting in large retail stores is not only meant to illuminate the space but also to highlight product displays. With its modularity, LumiLine LED 3.0 allows for the creation of specific lighting zones that can accentuate promotional displays or new offerings. Microprismatic diffusers can be used to create dynamic lighting around entrances or cash registers, attracting customers’ attention and improving overall navigation in the store.

Transit areas

In transit areas like corridors, passages, or staircases, lighting must ensure the safety and comfort of users. LumiLine LED 3.0, with its easy segment integration, can be used to create continuous light lines that guide users while providing sufficient illumination for signage and obstacles identification. Configuration flexibility also allows for adjusting light intensity according to the needs of different zones, such as brighter lighting at evacuation exits.

Commercial facilities

In retail spaces such as boutiques, shopping malls, or showrooms, LumiLine LED 3.0 can be utilized to create a unique atmosphere and accentuate architectural details and products. The modularity of the system allows for the creation of bespoke lighting solutions that highlight the character of a brand and capture customers’ attention, which is invaluable in shaping the shopping experience.

Product available in multiple configurations
NameProduct-CodeDimensions H x W x L [mm]Power [W].Luminosity [lm]Efficiency [lm/W]Color temperature [K]CRI/RaProtection Rating [IP]Light distribution
LUMILINE LED 3.0 1 LML3ST.10.011.8A3000
LML3ST.10.011.8A4000
LML3ST.10.017.8A3000
LML3ST.10.017.8A4000
 50/52/585
50/52/585
50/52/585
50/52/585
 11
11
17
17
 1300 – 1400
1350 – 1450
1950 – 2150
2050 – 2250
 118 – 127
122 – 131
114 – 126
120 – 132
 3000
4000
3000
4000
 >80
>80
>80
>80
 20
20
20
20
100°X105° 85°X90°
100°X105° 85°X90°

100°X105° 85°X90°
100°X105° 85°X90°

100°X105° 85°X90°
100°X105° 85°X90°

100°X105° 85°X90°
100°X105° 85°X90°
LUMILINE LED 3.0 2 LML3ST.20.032.8A3000
LML3ST.20.032.8A4000
 50/52/1225
50/52/1225
 32
32
 3850 – 4350
4100 – 4600
 120 – 135
128 – 143
 3000
4000
 >80
>80
 20
20
100°X105° 85°X90°
100°X105° 85°X90°

100°X105° 85°X90°
100°X105° 85°X90°
LUMILINE LED 3.0 3 LML3ST.30.046.8A3000
LML3ST.30.046.8A4000
 50/52/1799
50/52/1799
 46
46
 5850 – 6450
6150 – 6750
 127 – 140
133 – 146
 3000
4000
 >80
>80
 20
20
100°X105° 85°X90°
100°X105° 85°X90°

100°X105° 85°X90°
100°X105° 85°X90°
LUMILINE LED 3.0 4 LML3ST.40.076.8A3000
LML3ST.40.076.8A4000
 50/52/2945
50/52/2945
 76
76
 9750 – 10750
10250 – 11200
 128 – 141
134 – 147
 3000
4000
 >80
>80
 20
20
100°X105° 85°X90°
100°X105° 85°X90°

100°X105° 85°X90°
100°X105° 85°X90°
