LED lighting in the Geberit production area improving efficiency.
Skylight LED 4.0 Luminaire 1

Skylight LED 4.0

IP65 protection rating
Quick and simple installation thanks to the quick connector
High impact resistance IK08
High resistance to external factors
Lifespan of up to 135,000 hours of illumination
Source of light : LED
CE Certification
Klasa odporności 0
I protection class
IK08 IP66
Impact Protection/Ingress Protection
220-240V 50/60Hz power supply

Discover Skylight LED 4.0, the future of outdoor lighting. This advanced fixture not only enhances visibility but also elevates safety levels, making it the perfect choice for facades of industrial and logistics buildings. With an impressive luminous flux of up to 44650 lm and three available color temperatures (3000K, 4000K, 5000K), it ensures every space is brilliantly illuminated. The fixture stands out for its corrosion resistance and ease of installation. Available in 8 power versions, from 22 W to a striking 278W, it allows for tailored lighting solutions. With an efficiency reaching 168 lm/W and 7 different beam angles, optimal illumination is guaranteed for every corner. The housing, made of high-pressure die-cast aluminum and powder-coated, combined with a diffuser made of 4mm thick tempered transparent glass, assures up to 8 years of warranty.

Skylight LED 4.0: Modern Outdoor Lighting



Advanced Technology for Excellent Performance
Skylight LED 4.0 is an innovative floodlight designed to accentuate the facades of industrial and logistics buildings, combining advanced technologies with energy efficiency. Its impressive luminous flux reaching up to 44,650 lm and three available color temperatures (3000K, 4000K, 5000K) guarantee excellent illumination, perfectly suited to various outdoor applications.



Adaptability and Flexibility of Use
With 8 power versions ranging from 22 W to 278 W, and seven different beam angles, the Skylight LED 4.0 floodlight offers unlimited design possibilities, allowing for perfect customization of lighting to the specific requirements of each space. With a luminous efficacy of 168 lm/W, it ensures maximum energy utilization, crucial for projects aiming for sustainable development.



Robustness and Durability of Construction
The solid construction of the floodlight, made of high-pressure die-cast aluminum, powder-coated in black RAL 9005, and a diffuser made of tempered glass with a thickness of 4 mm, ensures resistance to outdoor conditions, including corrosion and impacts. With protection against surges up to 10 kV, the product boasts a long lifespan, confirmed by a standard 5-year warranty, extendable up to 10 years.



Advanced Features for Easy Installation and Operation
Skylight LED 4.0 is equipped with a quick connector, speeding up the installation process, while additional features of the power supply, such as NFC, DALI-2, and 4DIM, enable easy management of the lighting and its adjustment to the user’s individual needs. Available color temperature options and diverse light distribution angles make this floodlight a versatile tool in creating outdoor spaces.



Summary
Skylight LED 4.0 represents a new standard in outdoor lighting, offering excellent performance, durability, and flexibility of use. Ideal for highlighting architecture, landscaping elements, and ensuring safety in outdoor areas, it becomes an indispensable element of modern lighting projects.

Skylight LED 4.0 Applications
Facades of Industrial Facilities

Skylight LED 4.0 is the ideal choice for highlighting the facades of industrial buildings due to its impressive luminous power and resistance to harsh weather conditions. The high-pressure die-cast aluminum, powder-coated construction ensures long-lasting resistance to corrosion, while the wide range of beam angles allows for precise directing of light onto selected architectural elements. Available in three color temperatures, it enables aesthetic customization of lighting to match the character of the building.

Outdoor parking lots

For outdoor parking areas, where safety and visibility are paramount, the Skylight LED 4.0 floodlight offers an efficient and reliable solution. Its sturdy construction and protection against surges up to 10kV ensure stable operation in any conditions, while high luminous efficacy significantly improves visibility, enhancing user safety. Easy installation with the quick connector greatly reduces assembly time.

Sports Facilities

Skylight LED 4.0 is an excellent choice for illuminating sports facilities such as stadiums, fields, tennis courts, or pools. Its high luminous power and various light distribution angles enable precise and efficient lighting of sports surfaces, which is crucial for the safety and comfort of athletes and spectators. Additionally, its sturdy construction and resistance to harsh weather conditions ensure reliability in any environment, while different color temperature options allow for creating an optimal environment for various sports disciplines and events.

Logistics Facilities

Skylight LED 4.0 floodlights are invaluable in logistics facilities, where efficiency and reliability of lighting are crucial. IK08 impact resistance and a sturdy housing ensure durability even in intensively used spaces, while high light efficiency guarantees excellent visibility, which is essential for smooth flow of goods and employee safety.

Recreational Areas

With the option to choose between different color temperatures and beam angles, the Skylight LED 4.0 floodlight is perfect for illuminating recreational areas such as walking paths, sports fields, or playgrounds. It provides evenly distributed light that enhances safety and user comfort, encouraging outdoor activities even after dark.

Product available in multiple configurations
NameProduct-CodeDimensions H x W x L [mm]Power [W].Luminosity [lm]Efficiency [lm/W]Color temperature [K]CRI/RaProtection Rating [IP]Light distribution
SKYLIGHT LED 4.0 1 SKL4ST.10.022.8A3000
SKL4ST.10.022.8A4000
SKL4ST.10.022.8A5000
275/67/280
275/67/280
275/67/280
22
22
22
2900 – 3500
3050 – 3650
3100 – 3700
131 – 159
138 – 165
140 – 168
3000
4000
5000
>80
>80
>80
65
65
65
110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

SKYLIGHT LED 4.0 2 SKL4ST.20.039.8A3000
SKL4ST.20.039.8A4000
SKL4ST.20.039.8A5000
275/67/280
275/67/280
275/67/280
39
39
39
4750 – 5700
5000 – 6000
5050 – 6050
121 – 146
128 – 153
129 – 155
3000
4000
5000
>80
>80
>80
65
65
65
110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

SKYLIGHT LED 4.0 3 SKL4ST.30.071.8A3000
SKL4ST.30.071.8A4000
SKL4ST.30.071.8A5000
400/78/422
400/78/422
400/78/422
71
71
71
9700 – 11350
10150 – 11400
10200 – 11400
136 – 159
142 – 160
143 – 160
3000
4000
5000
>80
>80
>80
66
66
66
110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 140°X140° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 140°X140° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 140°X140° 145°X35° 145°X65° 155°X35°

SKYLIGHT LED 4.0 4 SKL4ST.40.112.8A3000
SKL4ST.40.112.8A4000
SKL4ST.40.112.8A5000
400/78/422
400/78/422
400/78/422
112
112
112
15550 – 17900
16300 – 17950
16350 – 17950
138 – 159
145 – 160
145 – 160
3000
4000
5000
>80
>80
>80
66
66
66
110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

SKYLIGHT LED 4.0 5 SKL4ST.50.157.8A3000
SKL4ST.50.157.8A4000
SKL4ST.50.157.8A5000
400/78/422
400/78/422
400/78/422
157
157
157
21350 – 24500
22300 – 24550
22350 – 24550
135 – 156
142 – 156
142 – 156
3000
4000
5000
>80
>80
>80
66
66
66
110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

SKYLIGHT LED 4.0 6 SKL4ST.60.193.8A3000
SKL4ST.60.193.8A4000
SKL4ST.60.193.8A5000
400/78/422
400/78/422
400/78/422
193
193
193
25500 – 28000
26600 – 29200
26650 – 29250
132 – 145
137 – 151
138 – 151
3000
4000
5000
>80
>80
>80
66
66
66
110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

SKYLIGHT LED 4.0 7 SKL4ST.70.219.8A3000
SKL4ST.70.219.8A4000
SKL4ST.70.219.8A5000
445/60/582
445/60/582
445/60/582
219
219
219
29650 – 33100
31200 – 34800
31250 – 34950
135 – 151
142 – 158
142 – 159
3000
4000
5000
>80
>80
>80
66
66
66
110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

SKYLIGHT LED 4.0 8 SKL4ST.80.278.8A3000
SKL4ST.80.278.8A4000
SKL4ST.80.278.8A5000
445/60/582
445/60/582
445/60/582
278
278
278
37900 – 42300
39900 – 44500
39950 – 44650
136 – 152
143 – 160
143 – 160
3000
4000
5000
>80
>80
>80
66
66
66
110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

110°X110° 30°X30° 60°X60°
110°X110° 30°X30° 60°X60° 90°X90° 145°X35° 145°X65° 155°X35°

Customize your product variant and download the dedicated technical specification sheet

Already have a quote? Select the product family and then the product code that interests you to download an individual product sheet
