LED Luminaries
SQflat LED D1 1.1

SQflat LED D1 1.1

Quick and easy installation
Low UGR coefficients
Possibility of using a wired DALI system
5-year warranty confirming quality
Source of light : LED
CE Certification
III protection class
IP40
Ingress Protection
220-240V 50/60Hz power supply

The SQFlat LED D1 Lift 1 is a lighting fixture for modern spaces, delivering up to 126 lm/W and 5450 lumens with high CRI >80. It features a durable design with an IP40 rating and a matte microprismatic PS diffuser. Ideal for offices, commercial spaces, technical rooms, social areas, and public buildings, its ultra-slim design (1195mm x 295mm x 10mm) supports surface, recessed, and suspended mounting. With a 50,000-hour lifespan and 5-year warranty, it ensures reliable performance in temperatures from -20°C to +40°C.

Advanced Technology and Exceptional Efficiency



SQFlat LED D1 Lift 1 is a lighting fixture designed for modern spaces. Available in six power versions: 21W, 25W, 29W, 34W, 38W, and 44W, it offers a luminous efficiency of up to 126 lm/W, reaching a luminous flux of up to 5450 lumens. A high CRI >80 ensures faithful color rendering, which is crucial in areas where light quality matters.



Modern Design and Durability

The housing of the SQFlat LED D1 Lift 1 fixture is durable and aesthetically pleasing, with a matte microprismatic PS diffuser that evenly disperses light. With an IP40 protection rating, the fixture is protected against dust and moisture, making it an ideal choice for offices, commercial spaces, technical rooms, social rooms, and public buildings.



Flexible Mounting Options and Intelligent Control

Thanks to various mounting options – surface, recessed, and suspended – and the ability to control via the DALI system, the SQFlat LED D1 Lift 1 fixture offers maximum flexibility in adapting to different spaces. The ultra-slim design (1195mm x 295mm x 10mm) facilitates integration with various types of ceilings, ensuring quick and easy installation.



Optimal Light Quality

The SQFlat LED D1 Lift 1 panels are designed to provide excellent light quality. They offer an efficiency of 126 lm/W at a color temperature of 4000K (CRI80) and a lifespan of 50,000 hours. A low UGR makes this fixture ideal for office applications, providing comfortable working conditions.



Dimensions and Weight

Compact dimensions of 1195mm x 295mm x 10mm and a weight of 2.4 kg make the fixture easy to install and handle, making it a versatile solution for various interior types.



Reliability and Longevity

SQFlat LED D1 Lift 1 comes with a 5-year warranty, ensuring users peace of mind and confidence in long-term, trouble-free operation.

SQflat LED D1 1.1 Applications
Office spaces

SQFlat LED D1 Lift 1 is perfect for modern offices. Efficiency up to 126 lm/W and CRI >80 ensure comfortable working conditions, while low UGR minimizes glare. The 90°x90° beam angle guarantees even lighting throughout the space.

Retail facilities

SQFlat LED D1 Lift 1 is excellent for commercial spaces with its solid construction and even light distribution. The slim design allows easy installation, and the 90°x90° beam angle ensures excellent illumination of every corner, enhancing product attractiveness.

Technical rooms

Ideal for technical rooms, SQFlat LED D1 Lift 1 offers high efficiency and reliability. The solid construction and IP40 protection ensure durability, while the 90°x90° beam angle guarantees bright and even lighting.

Social spaces

SQFlat LED D1 Lift 1 provides comfortable lighting in social rooms. Surface, recessed, and suspended mounting options and the 90°x90° beam angle ensure even lighting, promoting relaxation.

Public facilities

In public buildings like schools and offices, SQFlat LED D1 Lift 1 offers reliable and durable lighting. The beam angle ensures even lighting, improving safety and comfort for users.

Product available in multiple configurations
NameProduct-CodeDimensions H x W x L [mm]Power [W].Luminosity [lm]Efficiency [lm/W]Color temperature [K]CRI/RaProtection Rating [IP]Light distribution
SQFLAT LED D1 1.1 1 SQF1D1.11.021.8A3000
SQF1D1.11.021.8A4000
SQF1D1.31.029.8A4000
 295/10/1195
295/10/1195
295/10/1195
 21
21
29
 2500
2650
3650
 119
126
125
 3000
4000
4000
 >80
>80
>80
 40
40
40
90°X90°
90°X90°

90°X90°
90°X90°

90°X90°
90°X90°
SQFLAT LED D1 1.1 2 SQF1D1.21.025.8A3000
SQF1D1.21.025.8A4000
SQF1D1.41.034.8A4000
 295/10/1195
295/10/1195
295/10/1195
 25
25
34
 3000
3150
4200
 120
126
123
 3000
4000
4000
 >80
>80
>80
 40
40
40
90°X90°
90°X90°

90°X90°
90°X90°

90°X90°
90°X90°
SQFLAT LED D1 1.1 3 SQF1D1.31.029.8A3000
SQF1D1.31.029.8A4000
SQF1D1.51.038.8A4000
 295/10/1195
295/10/1195
295/10/1195
 29
29
38
 3500
3650
4700
 120
125
123
 3000
4000
4000
 >80
>80
>80
 40
40
40
90°X90°
90°X90°

90°X90°
90°X90°

90°X90°
90°X90°
SQFLAT LED D1 1.1 4 SQF1D1.41.034.8A3000
SQF1D1.41.034.8A4000
SQF1D1.61.044.8A4000
 295/10/1195
295/10/1195
295/10/1195
 34
34
44
 4000
4200
5450
 117
123
123
 3000
4000
4000
 >80
>80
>80
 40
40
40
90°X90°
90°X90°

90°X90°
90°X90°

90°X90°
90°X90°
SQFLAT LED D1 1.1 5 SQF1D1.11.021.8A3000
SQF1D1.51.038.8A3000
SQF1D1.51.038.8A4000
 295/10/1195
295/10/1195
295/10/1195
 21
38
38
 2500
4500
4700
 119
118
123
 3000
3000
4000
 >80
>80
>80
 40
40
40
90°X90°
90°X90°

90°X90°
90°X90°

90°X90°
90°X90°
SQFLAT LED D1 1.1 6 SQF1D1.61.044.8A3000
SQF1D1.61.044.8A4000
 295/10/1195
295/10/1195
 44
44
 5200
5450
 118
123
 3000
4000
 >80
>80
 40
40
90°X90°
90°X90°

90°X90°
90°X90°
SQFlat LED D1 1.1 Files
Catalog card SQFlat LED D1 1.1
pdf
Declaration of Conformity SQFlat LED D1 1.1
pdf
Installation instructions SQFlat LED D1 1.1
pdf
Photometric files SQFLAT LED D1 1.1
zip
Product photos – SQFlat LED D1 1.1
zip
