Elemento LED 1; Power version 1; Lift 0; 32W; CRI80; Midpower; 4000K; Lens PC; 90°x90°; DALI; Ta -25/+50°C; Warranty 5 years; Through wiring
32
5650
176
4000
>80
90°X90°
2,9
Power consumption 32 W. Luminous efficacy 176 lm/W. Luminous flux of 5650 lm. Spread of light 90°X90°. Luminaire intended for use in: Production halls, high-bay warehouse / high storage warehouse, Open space, Communication routes
Luminaire IP rating 44. Mechanical resistance IK 08. Acceptable ambient temperature Ta min -25°C - Ta max +50°C. Optical system made of PC. The luminaire uses Samsung LEDs with colour temperature tolerance (acc. to MacAdam ellipses) SDCM 3. Colour temperature 4000 K. Average rated life of L80B10 at 90 000 hours at Ta = 25°C. Average rated life of L80B10 at 90 000 hours at Ta = 35⁰C.
Average rated life of L80B50 at 90 000 hours at Ta = 25°C. Average rated life of L90B10 at 40 000 hours at Ta = 25°C. The product is classified for photobiological risk RG1. Colour rendering index (CRI) > >80 Ra.
The operating time of the power supply is 100 000 hours at Ta = 25°C. Power Factor (PF) 0,93. Total harmonic distortions (THD) 15%. The luminaire operates on a 198-264V 50-60Hz 176-280V DC power supply. Output current ripple 2%%. The lifetime of the luminaire is 90 000 h at 25°C. It can be controlled by DALI.
Dimensions: 63 mm height 1210 mm length 72 mm width. Housing material Extruded anodized aluminum, in gray color - RAL 7038. The weight of the luminaire is 2,9 kg. Maxnumber of luminaires in one circuit for: B10 = 19 B16 = 31 C10 = 33 C16 = 53.
| General information | |
|---|---|
| Warranty [Y] | 5Y |
| Quick connector | NO |
| Montage System | surface-mounted, suspended |
| External installation | YES |
| Protection rating | I |
| Internal installation | NO |
| IP protection class | 44 |
| Control system | DALI |
| Through wiring system | NO |
| Luminaire operating temperature | -25 ÷ +50 |
| Electrical data | |
|---|---|
| THD [%] | 15 |
| Power | 198-264V 50-60Hz 176-280V DC |
| Rated power [W] | 32 |
| Inrush current [A] | 25 |
| Max. number of luminaires in a single B10 circuit | 19 |
| Max. number of luminaires in a single B16 circuit | 31 |
| Max. number of luminaires in a single C10 circuit | 33 |
| Max. number of luminaires in a single C16 circuit | 53 |
| Power Supply System Data | |
|---|---|
| Power supply version | DALI |
| Current ripple [%] | 2% |
| Overvoltage protection (L-N)/(L/N-PE) [kV] | 1kV/2kV |
| Power supply lifetime for Ta=25°C [h] | 100 000 |
| Additional power supply features | DALI |
| Light source data | |
|---|---|
| LED brand Samsung | Samsung |
| L80B10; Ta=25°C [h] | 90 000 |
| L80B10; Ta=35°C [h] | 90 000 |
| L80B10; Ta=40°C [h] | 85 000 |
| L80B50; Ta=25°C [h] | 90 000 |
| L90B10; Ta=25°C [h] | 40 000 |
| Photobiological safety | RG1 |
| LED thermal resistance [K/W] | 7,5 |
| LED efficiency [lm/W] Ta=25°C | 197 |
| Driving current [mA] | 340 |
| Materials | |
|---|---|
| Housing color | gray |
| Lens material | PC |
| Housing material | Extruded anodized aluminum |
| Diffuser material | not available |
| Housing RAL | 7038 |
| Impact resistance (IK) | 08 |
| Luminaire photometric data | |
|---|---|
| UGR min. - max | 22 - 24 |
| Efficacy [lm/W] | 176 |
| Luminous flux [lm] | 5650 |
| Color rendering index (Ra) | >80 |
| Light beam angle | 90°X90° |
| Color temperature CCT [K] | 4000 |
| Standard deviation of color matching | 3 |
| Dimensions | |
|---|---|
| Width [W] | 72 |
| Height [H] | 63 |
| Length [L] | 1210 |
